80% Zirconia Beads

Name: Customized 80% Zirconia Beads Suppliers - Free Sample - KINGDA
Brand: Kingda
SKU: 137143559

Its widely used in various industries like medicine, food, cosmetics, paints, textiles, Structural Ceramics, Electronics Ceramics, Magnetic material, Metallurgy, printing and dyeing, pigment etc.

Send Inquiry

Product Details

Product Introduction

Zirconia toughened alumina grinding beads supplied by Duratec is popular among the customers, due to its low wear loss, it always used as grinding media, Its widely used in various industries like medicine, food, cosmetics, paints, textiles, Structural Ceramics, Electronics Ceramics, Magnetic material, Metallurgy, printing and dyeing, pigment etc.

Specification

Chemical Composition (Alumina Toughened Zirconia Bead Kingda Zr-85)
Element	Unit	Specification
ZrO₂ + HfO₂	Wt/%	80.0 ±5.0
Y₂O₃	Wt/%	5.0 ±0.5
Al₂O₃	Wt/%	15.0 ±5.0
Fe₂O₃	Wt/%	<2
SiO₂	Wt/%	<3
TiO₂	Wt/%	<1
Na₂O	Wt/%	<1
MgO	Wt/%	<1
CaO	Wt/%	<1

Physical Properties (KD-ZR85-10)
Lot No. 200118	200118
Specific Density (g/cm³)	5.21 (>5.1)
Bulk Density (g/cm³)	3.22 (>3.1)
Hardness (Hv)	1132.7±12.3 (>1050)
Roundness (%)	>94
Crushing Strength (kgf)	51.3±4.8 (>40)
Quantity (kg)	150
Beads Size (mm)	1.121±0.083

Application

It is especially suitable for vertical mixing mill, horizontal rolling ball mill, vibration mill and all kinds of rod pin sand grinder with high linear speed, etc. The application fields are as follows:

(1) Wear resistance, corrosion resistance products: coatings, textiles, pigments, printing and dyeing.

(2) High strength, high toughness products: magnetic materials, piezoelectric ceramics, dielectric ceramics.

(3) Pollution prevention: medicine, food, cosmetics.

(4) Ceramics: electronic ceramics, refractory ceramics, structural ceramics.

Advantages

Low, there is no pollution to the material, it is specially used for basket grinder, horizontal sand mill, bead mill, especially the preferred grinding bead for rod pin grinding equipment with very high linear speed.

Packing & Delivery
