Zirconia Ceramic Beads for Raw Material of Battery

Name: Customized Zirconia Ceramic Beads for Raw Material of Battery Suppliers - Free Sample - KINGDA
Brand: Kingda
SKU: 173912591

Kingda Y-TZP consists of yttrium stabilized zirconium oxide. Yttrium Stabilized Zirconia (Y-TZP) is the strongest ceramic material we offer. Y-TZP is a purely tetragonal phase, fine grain material.Mainly used for ultra-fine grinding and dispersing of "zero pollution" and high viscosity and high hardness materials.

Send Inquiry

Product Details

Product Introduction:

Zirconia Ceramic Beads for Raw Material of Battery consists of yttrium stabilized zirconium oxide. Yttrium Stabilized Zirconia (Y-TZP) is the strongest ceramic material we offer. Y-TZP is a purely tetragonal phase, fine grain material.

Chemical Composition:

Composition	ZrO₂	Y₂O₃	Other
Content %	94.8±0.2	5.1±0.1	0.1%

Physical Properties:

Specific Gravity g/cm³	Bulk Density g/cm³	Hardness Hv	Fracture Toughness MPam^1-2	Crushing Load KN (Φ2.0mm)	Grain size um	Wear loss (%)	Sphericity (%)
≥6.02	≥ 3.70	≥1250	9	≥20	≤0.5	≤0.08	≥98

Ball Sizes:

Size (mm)	Size (mm)	Size (mm)	Size (mm)	Size (mm)
Φ0.08-0.12	Φ0.12-0.18	Φ0.18-0.22	Φ0.22-0.28	Φ0.28-0.35
Φ0.3-0.4	Φ0.4-0.6	Φ0.6-0.8	Φ0.8-1.0	Φ1.0-1.2
Φ1.2-1.4	Φ1.4-1.6	Φ1.6-1.8	Φ1.8-2.0	2.0-2.2
Φ2.2-2.4	Φ2.4-2.6	Φ2.6-2.8	Φ2.8-3.0	Φ3.0-3.2
Φ3.2-3.5	Φ4	Φ5	Φ6	Φ7
Φ8	Φ10	Φ12	Φ15	Φ17
Φ20	Φ25	Φ30	Φ40	Φ50

Applications:

Zirconia Ceramic Beads for Raw Material of Battery widely used for grinding, dispersing and polishing as following: inkjets inks, electronic slurries, raw material of battery, screen printing inks, coating, painting, pigment, ceramic and cosmetic, jewelry and other nanoparticles products.

Production Details:

Display Cabinet:

951

952

IMG_20210316_152532

Main advantage

Zirconia Ceramic Beads for Raw Material of Battery is one of biggest manufacture to make ceramic grinding media ball in China.

SGS, ROHS certificate,Strict quality control system ISO 9001.
Professional,Sincerity,Concentration,Honesty,Constant striving for improvement,Mutual Glory.

High Quality raw material imported from Australian.

 Quick-delivery, safe packing

Features:
A. Long lifespan: 30 times longer life than glass beads, 6 times than zirconium silicate beads.

B.High efficiency: around 6 times higher than glass beads; 2 times than zirconium silicate beads.

C. Excellent wear resistance and fracture toughness is especially suited for high-solid-phase high viscosity, high hardness of thepaste for grinding and dispersing of pure; good match at the same
time high input energy and the high shear machine sanding.

FAQ:

Why is yttria used to stabilize zirconia?	Yttria-stabilized zirconia (YSZ) is currently the mostly commonly used electrolyte due to its acceptable performance, pure oxygen ion conductivity, and suitable chemical stability. We have an exclusive offer for our members..
What does yttrium do to zirconia?	Substituting some of the zirconium ions for yttrium stabilizes the cubic phase of the material, which is normally only formed at very high temperatures (>2690 °C) over a wide temperature range. This allows sintered zirconia products to be created, and also makes the material a conductor of O2- ions.Please come in and have a look at our best sellers.
