ceria stabilized zirconia beads

The ceria stabilized zirconia beads are made from a combination of tough, high strength, Tetragonal Zirconia Polycrystal (TZP) materials. These tighter microstructures can enhance wear resistance in the milling process.

Send Inquiry

Product Details

Ceria stabilized zirconia beads

Product Introduction:

Chemical Composition:

Composition	ZrO₂	CeO₂ + Others
Content %	≥80	≤20

Typical Properties:

Specific Gravity g/cm³	Bulk Density kg/L	Bending Strength MPa	Hardness HV1	Fracture Toughness MPam1-2	Crushing Load Kgf (Φ1.50mm)	Sphericity
≥5.95	≥3.70	1000-1200	≥1150	7	≥70	≥97

Sizes Φ:

Size (mm)	Size (mm)	Size (mm)	Size (mm)
0.3-0.5m	1.0-1.2	1.8-2.0	2.6-2.8
0.4-0.6	1.2-1.4	2.0-2.2	2.8-3.0
0.6-0.8	1.4-1.6	2.2-2.4	3.0-3.2
0.8-1.0	1.6-1.8	2.4-2.6	5, 8, 10, 20.

Features:

1.	Its excellent wear resistance and fracture toughness is particularly suited for high-solid-phase high-viscosity.
2.	High efficiency: around 2 to 3 times higher than zirconium silicate beads.
3.	Low contamination: no cross contamination and color shade from beads and mills.
4.	It has high grinding efficiency, making it suitable for aqueous agricultural chemicals.

Applications:

It is applied to the grinding high viscosity pastes such as screen printing inks, offset inks, CaCO₃, metal minerals; and high purity products such as pharmaceutical and foodstuff.

Production Details

Deliver, Shipping and Serving:

Quantity (Kilograms)	1 - 200	201 - 500	>500
Est. Time (days)	3	7	To be negotiated

Ceria Zirconia

FAQ

1. What's product your company supply?

A.	We can supply yttria zirconia oxide bead, cerium stabilized zirconia bead, zirconium silicate bead, 92% high alumina ball, agate ball, zirconia toughened alumina beads, ball mill grinding jar with different materials, etc.

2. Q: What is your MOQ?

A: 1KG. We accept smaller quantity.

3. Q: Can you provide free samples?

A: Yes, the buyers just afford shipping cost.

4. Q: What is your payment term?

A: T/T 30% Deposit, balance against copy of B/L. L/C at sight, Western Union, pay pal, Visa, etc.
