Home > Products > Ceramic Grinding Media > Zirconia Ceramic
small size ysz grinding media

small size ysz grinding media

Applied in Grinding, Polishing, etc.
1. Wear and corrosion resistant product: coating, textile, pigment, dyeing
2. High strength, high tenacity product: magnetic material, piezoelectric ceramics, dielectric ceramics
3. Pollution prevention: medicine, food, cosmetics
4. Ceramics: electronic ceramics, refractory ceramics, structural ceramics
Send Inquiry
Product Details

Small size ysz grinding media

Products Description


 Kingda Y-TZP consists of yttrium stabilized zirconium oxide. Yttrium Stabilized Zirconia (Y-TZP) is the strongest ceramic material we offer. Y-TZP is a purely tetragonal phase, fine grain material.


Chemical Composition


Composition

ZrO2

Y2O3

Other

Content %

94.8±0.2

5.1±0.1

0.1%


Physical Properties


Specific Gravity g/cm3

Bulk Density g/cm3

Hardness Hv

Fracture Toughness MPam1-2

Crushing Load KN (Φ2.0mm)

Grain size um

Wear loss (%)

Sphericity (%)

≥6.02

≥ 3.70

≥1250

9

≥20

≤0.5

≤0.08

≥98


Ball Size Φ


Size (mm)

Size (mm)

Size (mm)

Size (mm)

Size (mm)

Φ0.08-0.12

Φ0.12-0.18

Φ0.18-0.22

Φ0.22-0.28

Φ0.28-0.35

Φ0.3-0.4

Φ0.4-0.6

Φ0.6-0.8

Φ0.8-1.0

Φ1.0-1.2

Φ1.2-1.4

Φ1.4-1.6

Φ1.6-1.8

Φ1.8-2.0

2.0-2.2

Φ2.2-2.4

Φ2.4-2.6

Φ2.6-2.8

Φ2.8-3.0

Φ3.0-3.2

Φ3.2-3.5

Φ4

Φ5

Φ6

Φ7

Φ8

Φ10

Φ12

Φ15

Φ17

Φ20

Φ25

Φ30

Φ40

Φ50


Application


It is widely used for grinding, dispersing and polishing as following: inkjets inks, electronic slurries, raw material of battery, screen printing inks, coating, painting, pigment, ceramic and cosmetic, jewelry and other nanoparticles products.


Products Details


_DSC8512_DSC8533

_DSC8542

_DSC8699


















Customer Feedback


952


IMG_20210316_141158



Main Advantage
1.It is one of biggest manufacture to make ceramic grinding media ball in China.

2.SGS, ROHS certificate,Strict quality control system ISO 9001.

3.Professional,Sincerity,Concentration,Honesty,Constant striving for improvement,Mutual Glory.

4.High Quality raw material imported from Australian.

5.  Quick-delivery, safe packing


Features

A. Long lifespan: 30 times longer life than glass beads, 6 times than zirconium silicate beads.

B.High efficiency: around 6 times higher than glass beads; 2 times than zirconium silicate beads.

C. Excellent wear resistance and fracture toughness is especially suited for high-solid-phase high viscosity, high hardness of thepaste for grinding and dispersing of pure; good match at the same time high input energy and the high shear machine sanding.

How are zirconia beads made?

Small size ysz grinding media generally, high-quality microcrystalline zirconia grinding media is formed by using yttria-stabilized zirconia (Y-TZP) ultrafine powder as raw material and then densified by high-temperature sintering (1400-1600 ° C), and then self-grinding or adding super fine abrasive polishing.
